Compatible with 90% brands inverter in the market.
Smart BMS system to optimize the performance.
Reliable LFP cell, design life 15 years, over 6000 cycles life.
High power output, cover all kinds scenario, lower the investment.
Compatible with 90% brands inverter in the market.
Smart BMS system to optimize the performance.
Reliable LFP cell, design life 15 years, over 6000 cycles life.
High power output, cover all kinds scenario, lower the investment.
| Model | WV76120H | ||||||
| Battery Type | LiFePO4 | ||||||
| Capacity(kWh) | 9.216 | ||||||
| Nominal Voltage(V) | 76.8 | ||||||
| NominalCapacity(Ah) | 120 | ||||||
| Operating Voltage(V) | 67.2~86.4 | ||||||
| Standard Charge Current(A) | 120(1C) | ||||||
| Maximum Charge Current(A) | 150(1.25C)@5s | ||||||
| Standard Discharge Current(A) | 120(1C) | ||||||
| Maximum Discharge Current(A) | 150(1.25C)@5s | ||||||
| Cooling Method | Forced Air Cooling | ||||||
| Dimension(W*D*H)(mm) | 468*642*202 | ||||||
| Weight(Kg) | 90±1.5 | ||||||
| Communication | CAN | ||||||
| Cycle Life | >6000(25℃) | ||||||
| Depth Of Discharge | 80% |
